I’ve been playing with terminal emulators again for a while. More to write up at some point, but here a quick note on some customisations for displaying images in the terminal….

There are a couple of terminal emulators which allow for display of arbitrary images in the terminal (I mean, jpegs and pngs and the like, not (just) sixel), notably Kitty and WezTerm.

WezTerm with iTerm2 compatible image protocol support, and built-in imgcat command, alongside of (experimental but seemingly working) support for Kitty’s image display protocol (enable this in WezTerm by adding to your wezterm.lua config the line enable_kitty_graphics=true).

I mainly use Fish shell, and here I record a couple of notes on convenience customisations in Fish for working with in-terminal image display in Kitty and WezTerm. But, I have a POSIX-compatible (including Bash) version (less well tested) included below as well.

WezTerm’s command to display an image in the terminal is wezterm imgcat </path/to/image/file>, and Kitty’s is kitten icat </path/to/image/file>.

I’m playing with both terminals, and have a hard time remembering things, so one thing I’ve done is to alias these commands in fish to just icat.

More significantly, while WezTerm seems to have a smart auto-sizing of the image to downsize the rendering to make sure the image fits fully within the current terminal window, Kitty only seems to guarantee downsized display to make sure the image fits the current width of the terminal window, but does not downsize to fit the current height of the terminal window.

Thus, in Kitty, we get things like this:

(….hmm, boots aren’t a kitty…)

While in WezTerm, we get:

And with appropriate configuration from below added, the new (easy-to-remember) icat command works to produce in-terminal image display as in WezTerm:

(…and there’s the kitty in Kitty!)

Here are the relevant lines that can be added to your shell configuration file to both make the image display command in both Kitty and WezTerm both simply icat, and also resize the display of the image in Kitty to make sure it fits lengthwise in the current terminal window:

Fish shell #

#################### BEGIN image display things ######################

# image display things for kitty [https://sw.kovidgoyal.net/kitty/]
#                        & wezterm [https://wezfurlong.org/wezterm/]
#
# - use 'icat $path/to/image' (in either) to display image in terminal
# - on inner workings of the image display protocols, see:
#   - for kitty:    https://sw.kovidgoyal.net/kitty/kittens/icat/
#   - for wezterm:  https://wezterm.org/cli/imgcat.html

# if we're in kitty:
if [ "$TERM" = "xterm-kitty" ]
alias icat-full "kitten icat" # alias the default kitty icat behaviour to `icat-full'

# function icat-auto
function icat  # define auto-resizing version of kitty's `icat'
# calculate kitty window size parameters:
set -l kittysize (kitten icat --print-window-size) # get kitty window size
set -l kittywidth (echo $kittysize | cut -dx -f1) # extract width of kitty window
set -l kittyheight (echo $kittysize | cut -dx -f2) # extract height of kitty window
set -l argcount (count $argv)    # count how argumnets to icat there are

# calculate target image size parameters: [requires ImageMagick!]
set -l imagesize (identify -format '%wx%h' "$argv[$argcount]")  # `identify' is part of ImageMagick
set -l imagewidth (echo $imagesize | cut -dx -f1) # extract width of image
set -l imageheight (echo $imagesize | cut -dx -f2) # extract height of image
set -l reducebyy 1.0  # initialise and set to '100%' [no change] y-axis reduction percentage
set -l reducebyx 1.0  # initialise and set to '100%' [no change] x-axis reduction percentage

# test if target image is bigger than kitty window
if [ $imageheight -gt $kittyheight ] # if it's taller than the terminal window
# divide terminal window height by image height
set reducebyy (math $kittyheight / $imageheight)
end
if [ $imagewidth -gt $kittywidth ]  # if it's widre than the terminal window
# divide terminal window width by image width
set reducebyx (math $kittywidth / $imagewidth)
end
if [ $reducebyy -lt $reducebyx ]  # set both reducebyx, reducebyy to smallest of 2 values
set reducebyx $reducebyy
else
set reducebyy $reducebyx
end
# calculate target image height and width to fit fully in terminal window
set imageheight (math floor (math $reducebyy x $imageheight))
set imagewidth (math floor (math $reducebyx x $imagewidth))

# call the `kitten icat' kitty command using the calculated image size
if [ "$argcount" -gt 1 ] # if the user has passed more args than just the target image filepath
# then pass all of those separately along with `--use-window-size' parameter
command kitten icat --use-window-size $COLUMNS,$LINES,"$imagewidth","$imageheight" $argv[1..(math (count $argv) - 1)] $argv[(count $argv)]
else
command kitten icat --use-window-size $COLUMNS,$LINES,"$imagewidth","$imageheight" $argv[1]
end
end

# if we're in WezTerm, alias `icat' to wezterm's imgcat
else if [ "$TERM_PROGRAM" = "WezTerm" ]
alias icat "wezterm imgcat"
# NOTE: currently not sure best way of emulating kitty's default image display behaviour
#      - mainly because I don't know how to get the WezTerm window size in a
#        fashion that's window-manager neutral and neutral between
#        graphical display protocol (i.e., X11 vs Wayland)

# draft version of default kitty icat-like behaviour for `imgcat'
# function icat-full
#   set -l imagesize (identify -format '%w' "$argv[$argcount]")
# end
# alias icat-full "wezterm imgcat --width 100%"
end

#################### END image display things ######################

POSIX shell (including Bash) #

#################### BEGIN image display things ######################

# image display things for kitty [https://sw.kovidgoyal.net/kitty/]
#                        & wezterm [https://wezfurlong.org/wezterm/]
#
# - use 'icat $path/to/image' (in either) to display image in terminal
# - on inner workings of the image display protocols, see:
#   - for kitty:    https://sw.kovidgoyal.net/kitty/kittens/icat/
#   - for wezterm:  https://wezterm.org/cli/imgcat.html

# if we're in kitty:
if [ "$TERM" = "xterm-kitty" ]
then
alias icat_full="kitten icat" # alias the default kitty icat behaviour to `icat-full'

icat () { # define auto-resizing version of kitty's `icat'
# calculate kitty window size parameters:
kittysize="$(kitten icat --print-window-size)" # get kitty window size
kittywidth="$(echo $kittysize | cut -dx -f1)" # extract width of kitty window
kittyheight="$(echo $kittysize | cut -dx -f2)" # extract height of kitty window

# calculate target image size parameters: [requires ImageMagick!]
icat_last_arg_pos="\${$#}"
icat_last_arg_content="$(eval echo \"$icat_last_arg_pos\")"
identify_command="identify -format '%wx%h' \"$icat_last_arg_content\"" # `identify' is part of ImageMagick
imagesize="$(eval $identify_command)"
imagewidth="$(echo $imagesize | cut -dx -f1)" # extract width of image
imageheight="$(echo $imagesize | cut -dx -f2)" # extract height of image
reducebyy=100  # initialise and set to '100%' [no change] y-axis reduction percentage
reducebyx=100  # initialise and set to '100%' [no change] x-axis reduction percentage

# test if target image is bigger than kitty window
if [ "$imageheight" -gt "$kittyheight" ] # if it's taller than the terminal window
then
# divide terminal window height by image height
reducebyy=$(( ( kittyheight * 100 ) / imageheight ))
fi
if [ "$imagewidth" -gt "$kittywidth" ]  # if it's wider than the terminal window
then
# divide terminal window width by image width
reducebyx=$(( ( kittywidth * 100 ) / imagewidth ))
fi
if [ "$reducebyy" -lt "$reducebyx" ]  # set both reducebyx, reducebyy to smallest of 2 values
then
reducebyx="$reducebyy"
else
reducebyy="$reducebyx"
fi
# calculate target image height and width to fit fully in terminal window
imageheight=$(( ( reducebyy * imageheight ) / 100 ))
imagewidth=$(( ( reducebyx * imagewidth )  / 100 ))
kitten icat --use-window-size $COLUMNS,$LINES,$imagewidth,$imageheight "$@"
}
# if we're in WezTerm, alias `icat' to wezterm's imgcat
elif [ "$TERM_PROGRAM" = "WezTerm" ]
then
alias icat="wezterm imgcat"
fi

#################### END image display things ######################

Note about built-in capacity #

I confirmed with the developer, Kovid Goyal, that currently Kitty does not have an “autofit” option (other than it’s default autofit to fit width), see GitHub issue #9201. But Kovid seems to have gone ahead and added a built-it --fit option for Kitty, so a built-in way of managing image display with respect to window size should be available natively in an upcoming Kitty release.
